DESANDER

The desander is a dust cleaning system specifically designed to remove heavy pollutants within a mesh range from 0.1 to 0.6 mm. The machine utilizes a specially designed separation chamber where the dust flow is crossed by two adjustable air currents, generated by fans equipped with inverters. Thanks to an internal rotor that balances the flow and a precise dosing system, the desander ensures very high cleaning efficiency in sand removal. Its compact layout, combined with low energy consumption and minimal maintenance costs, makes it an essential solution for treating polluted dust flows.

Proudly made by

Best in class for

WOOD BASED PANELS

PB/SPB

Technical features

Dust cleaning system suitable to remove heavy pollutants within a mesh range from 0.1 to 0.6 mm
Specially designed chamber for separating heavy pollutants from dust
Two adjustable air flows crossing the chamber from the fans equipped with inverter
Dosing system for setting the feeding flow
Internal rotor for balancing the dust flow inside the chamber

Benefits

Removal of sand from the dust flow
Very high cleaning efficiency
Compact layout
Very low maintenance costs
Low energy consumption

Gallery

Technical features

MODEL	OVERALL DIMENSIONS mm
MODEL	A	B	C	D	E
DS.100	3940	1874	4624	4722	950

MODEL	CAPACITY* m3/h	TOTAL INSTALLED POWER kW	SUCTION S1			WEIGHT APPROX. kg
MODEL	CAPACITY* m3/h	ALL MOTORS	SUCTION m3/h	AIR SPEED m/s	PIPE DIMENSION Ø mm	WEIGHT APPROX. kg
DS.100	4-6	4,83	1 x 8000	25	350	2760
*According to type of infeed material
