PALLETLAB

PROUDLY MADE BY

Best in class for

PRESSED WOOD PACKAGING
WOODEN PALLETS, PRESSED PALLETS

Technical features

PALLETLAB is a machine for testing the quality and mechanical characteristics of wooden pallets in various conditions and then processes the results obtained. PALLETLAB combines simplicity of use with safe and reliable operation thanks to a microprocessor that controls the data measurement process, and an optimized HMI interface designed to carry out the tests and efficiently obtain the measure-ment results. It comes complete with a set of accessories to conduct all the tests in compliance with current ISO standards.

IMPLEMENTED STANDARDS
The PALLETLAB is designed to perform tests in compliance with the following in-ternational standards:
• ISO 8611-1 part 1a – bending strength in racking situations.
• ISO 8611-1 part 2a – bending strength in forklifting situations.
• ISO 8611-1 part 4a – bending strength in stacking situations.

Vantaggi

  • The PALLETLAB has been engineered to perform compression tests on standard 1200×800 mm wood-based pallets, with forces up to 10000 kgF.

Gallery

Technical features

TECHNICAL DATA
INSTALLED POWER
2 Kw
MAXIMUM PALLET DIMENSIONS
800 x 1200 mm
MAXIMUM LOAD
10000 kg
