HAMMERMILLS – FALCON

The machine is designed for refining pre-ground material.

PROUDLY MADE BY

WOOD BASED PANELS

MDF/HDF, INSULATION BOARDS

PELLET & ENERGY

WOOD PELLETS AND BLACK PELLETS, THERMAL AND ELECTRIC ENERGY

WOOD RECYCLING AND WASTE TREATMENT

CUSTOMIZED SOLUTIONS FOR RECYCLING

Secure optimum size reduction of different type of biomass and products
High efficiency Hammermills family thanks to the right combination of hammers, speed, nets, correct negative pressure values and a proper feeding system
Special design to refine both fresh and recycling chips
Rotor with theories of easily replaceable hammers
Special hammers and impact segments protected against wear
Fast replacement of perforated screens
Large screen area
Feeding provided with protection devices to reject heavy pollutants

MODEL	CAPACITY* CHIPS & MICRO-CHIPS t/h	INSTALLED POWER kW					WEIGHT APPROX. kg
MODEL	CAPACITY* CHIPS & MICRO-CHIPS t/h	M1*	M1.1	M2	M3	M4	STANDARD	OPTIONS
FALCON 50/50	1 - 2	22 - 37	-	-	-	-	1025	-
FALCON 105/85.EVA.MD.WS	4 - 7	132 - 160	-	2 x 0,9	1,5	2,2	4500	2000
FALCON 105/120.EVA.MD.WS	7 - 8	200 - 250	-	2 x 0,9	1,5	2,2	5500	2300
FALCON 125/195.EVA.MD.WS	11 - 12	250 - 315	-	2 x 1,3	1,5	2 x 2,2	8800	3370
FALCON 180/200.EVA.MD.WS	14 - 16	400 - 630	0,75	2 x 3,0	1,5	2 x 4,0	16500	5000
*According to type of material, moisture content and mesh size of perforated screens.
