EOLO

The machine is designed to separate woodchips from heavy bodies via separation/selection carried out using an air current.

PROUDLY MADE BY

Best in class for

WOOD BASED PANELS

PB/SPB

PRESSED WOOD PACKAGING

PALLET BLOCKS

PELLET & ENERGY

WOOD PELLETS AND BLACK PELLETS, THERMAL AND ELECTRIC ENERGY

Heavy material removal (stones, glass, heavy plastic, etc…) from chips flow by air blowing
Simple construction
Easily adjustable separation into two fractions
High separation efficiency
Great reliability
Very low maintenance cost
Very low energy consumption

MODEL	OVERALL DIMENSIONS APPROX. mm						TOTAL INSTALLED POWER kW	CAPACITY BULK CHIPS m3/h	NET WEIGHT APPROX. kg	EXHAUST AIR m3/h
MODEL	A	B	C	D	E	F	TOTAL INSTALLED POWER kW	CAPACITY BULK CHIPS m3/h	NET WEIGHT APPROX. kg	EXHAUST AIR m3/h
EOLO 10	2580	5500	1680	1000	1690	500	13,5	70	2800	10000
EOLO 15	2580	5700	2180	1500	1690	500	21,5	100	3300	15000
EOLO 22	2723	5700	2880	2200	1690	500	25	150	4650	20000
EOLO 30	2760	6870	3755	3000	1910	500	41	200	5850	30000
